Factory supply Orange PI CM4 board Orange Pi Compute Module 4 board RockChip RK3566 chip

Model number: DB_OPICM4_01

Brand: Orange PI

Encapsulation: BTB

Inventory: 1000

Price: $29.00

Add to shopping cart

Product details
Quote Now

Description

Orange Pi Compute Module 4 is compact and powerful enough for deep embedded applications.Orange Pi Compute Module 4 is powered by Rockchip RK3566, a quad-core 64-bit Cortex-A55 processor, 22nm advanced process, up to 1.8GHz; integrated ARM Mali G52 2EE graphics processor, supporting OpenGL ES 1.1/2.0/3.2, OpenCL 2.0, Vulkan 1.1, embedded high-performance 2D acceleration hardware; integrated RKNN NPU AI accelerator, 0.8Tops@INT8 performance, supporting Caffe/TensorFlow/TFLite/ONNX/PyTorch/Keras/Darknet architecture model conversion with one click; provides rich interfaces, different specifications of eMMC flash memory and wireless modules, which can be widely used in industrial IoT field.

Features:
SoC: RockChip RK3566 CPU: Quad-core 64-bit Cortex-A55 processor，22nm advanced process, up to 1.8GHz main frequency GPU: • ARM Mali G52 2EE graphics processor • Supports OpenGL ES 1.1/2.0/3.2, OpenCL 2.0, Vulkan 1.1 • Embedded high performance 2D acceleration hardware NPU: • Integrated RKNN NPU AI gas pedal, 0.8Tops@INT8 performance • Supports Caffe/TensorFlow/TFLite/ONNX/PyTorch/Keras/Darknet VPU: • 4K@60fps H.265/H.264/VP9 video decoding • 1080P@100fps H.265 video encoding • 1080P@60fps H.264 video encoding PMU: RockChip RK809-5 RAM: 1GB/2GB/4GB/8GB （LPDDR4/4x） Memory: • On-board eMMC: 8GB/32GB/64GB/128GB • SPI Flash: default empty post Wi-Fi + Bluetooth: Wi-Fi 5+BT 5.0，BLE（20U5622） Ethernet transceivers: 10/100/1000Mbps Ethernet (on-board PHY chip : YT8531C) Interface: • 100Pin*2, 24Pin*1, contains the following signals: • 10/100/1000Mbps Ethernet MDI signals • 1* HDMI 2.0 interface up to 4K@60fps • 1* 2-lane MIPI DSI display interface • 1* 4-lane MIPI DSI display interface • Embedded Display Port (eDP) • 1* 4-lane MIPI CSI camera interface • SATA3 or PCIe • USB3.0*1+USB2.0*3 • RESET, MASKROM, RECOVERY • Headphone jack Audio input and output signals • DC 5V input power supply, DC3.3V and 1.8V output power supply Supported OS: Android 11, Ubuntu 22.04, Ubuntu 20.04, Debian 11, Debian 12, OpenHarmony 4.0 Beta1, Orange Pi OS (Arch), Orange Pi OS (OH) based on OpenHarmony and other operating systems. PCB: 55X40mm Weight: 12g
